Tools & Equipment Makita 7104L Powerful 12 Amp Motor Extremely Portable Chain Mortiser

“

Features

• Perfect for timber framing and log home building
• Extremely portable at only 37.4 lbs.
• Cuts lap joints up to 5-1/8
• Large adjustable vise for attaching firmly onto logs 3-1/8 to 12-1/8 thick
• Sliding rear clamp adjustable to desired width with a quick adjust tension knob
• Clamp tension lever for a firm hold on log
• Plunge depth adjustment in 1/8 increments
• Cutting line indication plate
• Adjust knob for re-adjusting position of chain across the log
• Quick horizontal chain lever for widening holes
• Chain tension adjustment cover with snap action
• Professional 12 AMP motor
• Razor sharp chain to quickly notch or cut holes
• Durable plastic boot protects twin steel rails
• Externally accessible carbon brushes for easy serviceability
• Built-in carrying handle for ease of transportation

What’s in The Box

• 23/32 (18.25 mm) Cutter Chain (A-16570)
• Sharpening Holder (123028-2)
• Wrench (781204-0)
• 100 cc Oil Supply (182229-1)
• Owner’s Manual

Warranty

• 1-Year Limited Factory Warranty
• 30 Day Satisfaction Guaranteed

Specifications

Capacity	Max Hole Width (Longitudinal) 5-1/8, Max. Hole Width (Transverse) 7-1/4, Max. Hole Depth 6-1/8
No Load RPM	3,200
Chain Speed (ft./min.)	1,000
AMPS	12.0
Size	15-1/4×11-3/4×20-1/4
Cord Length	16.4
Net Weight (lbs.)	37.4
Shipping Weight (lbs.)	44.0

“
