Powermatic 1791308 1285 230V/460V 3 HP 3 Phase 12″ Jointer Helical Head

Features

• Helical cutter head with 42 two-sided carbide inserts for fast knife changes with no adjustments and a quiet clean cut
• Rack and pinion adjustable cast iron fence assembly for smooth fence positioning without play
• Large 12″ x 84″ precision ground cast iron table surface for heavy-duty work
• Parallelogram design for close table-to-cutterhead proximity and fast depth of cut adjustments
• Table “lips” on both sides of cutterhead aid in noise reduction
• Full-size rabbeting ledge supports large workpieces for rabbets up to 3/4″ deep

What’s in The Box

• 1285 Jointer
• Owner’s Manual

Warranty

• 2 Year Limited Factory Warranty
• 30 Day Satisfaction Guaranteed

Specifications

SKU	1791308
Brand	Powermatic
Volts	230/460
Motor Phase	3
Horsepower	3
Type of Cutterhead	Helical
Number of Knives	42 Four Sided Carbide Helical Inserts, 2 Rabbet
Helical Knife Size (L x W x T)	1.18 x .472 x .079 in
Cutterhead Speed (RPM)	5000
Cutting Capacity (W x D)	11-3/4 x 3/4 in
Table Size (L x W)	84 x 12
Table Height from Floor	31-5/8 in
Rabbeting Capacity	3/4
Fence Size (L x H)	47-1/4 x 5-1/4 in
Fence Tilt	45 forward, 45 backward
Fence Positive Stops	45, 90 , -45
Dust Collection Minimum CFM Required	800
Dust Port Outside Diameter	4
Dimensions(L x W x H)	84 x 38 x 44 in
Weight	880 lbs
