Jet 321379 9-Inch X 29-Inch 115-Volt 3/4-Hp Standard Spindle Benchtop Lathe Tools & Equipment

Features

• Induction hardened and ground bedway
• Spindle supported by precision tapered roller bearings
• Safety on/off switch
• Emergency Stop within easy reach of the Operator
• Chuck Guard
• Quick change gearbox provides wide range of inch and metric threads
• Power longitudinal feed allows threading and reverse threading
• Quick locking tailstock
• Standard 1-1/2 x 8 TPI spindle mount allows for many aftermarket accessories
• Reversing switch for added versatility

What’s in The Box

• 9-Inch x 29-Inch Benchtop Lathe
• Owner’s Manual

Warranty

• 2-Year Limited Factory Warranty
• 30 Day Satisfaction Guaranteed

Specifications

Sku	321379
Brand	Jet
Voltage	115v
Horsepower	3/4 Hp
Phase	1-Phase
Number of Longitudinal and Cross Feed Rates	60
Number of Metric Threads	12
Max Tool Size	1/2 in.
Width of Bed	4-1/2 in.
Swing Over Bed	8-3/4 in.
Cross Slide Travel	4-1/4 in.
Taper in Tailstock Spindle	MT-2
Compound Slide Travel	1-7/8 in.
Range of Metric Threads	0.5 – 3.5
Carriage Travel	26.5 in.
Steady Rest Capacity	1-3/4 in.
Number of Inch Threads	27
Range of Spindle Speeds	130 Rpm – 2,000 Rpm
Spindle Mount	1-1/2 in. x 8 Tpi
Follow Rest Capacity	1-3/4 in.
Spindle bore	3/4 in.
Range of Inch Threads	8 Tpi – 56 Tpi
Spindle Taper w/ Sleeve	MT-3
Swing Over Cross Slide	5 in.
Number of Spindle Speeds	6
Tailstock Spindle Travel	1-9/16 in.
Distance Between Centers	27.5 in.
Range of Longitudinal Feeds	0.0006 Ipr – 0.0368 Ipr
Length	51 in.
Width	22 in.
Height	20 in.
Product Weight	287 lbs.
